In this article the Microsoft SDK ISAPI authentication filter sample was rewrited using MFC ISAPI classes. The filter’s funcionality remains exactly the same, the purpose of the article is to demonstrate the use of the MFC ISAPI classes to write filters. Note that this authentication filter is not the most trivial sample, it provides pretty serious functionality (Microsoft refers to it as “A Filter for Advanced Authentication”). The filter functionality is described below using an excerption of Microsoft documentation.
“AuthFilt demonstrates how to write an authentication filter based on an external datasource. Authentication is the process of accepting or denying a request from a client, so AuthFilt will be notified each time an authentication request comes in. This sample uses a file (userdb.txt) to keep track of authorized users, but you might modify this sample to access a database which holds user info.
For each authentication request, AuthFilt first looks in a cache of recently authenticated users, and when that fails, AuthFilt looks in the userdb.txt file. This shows an efficient way to authorize connections: a cache allows the filter to quickly authenticate users, and because each request comes in through the filter, speed is critical.”
The project is a standard appwizard generated ISAPI filter. The global functions of the AuthFilt Microsoft sample were encapsulated in the filter class. There are 3 parameters that can be changed to fine tune the filter: the maximum number of cached users, the position after which a cached entry will be moved to the front of the list (to make the search time shorter!) and the name of the file that contains the username/password pairs and the appropriate NT account the username/password should be mapped to. All this parameters are #define directives in the authflit.h header file.
The filter could be improved in several ways: using a database instead of a file for authentication information (you should consider using stored procedures to search and/or to cache!), load parameters from registry, automatic selection of the number of cached users and the list reorder parameter, etc.
The full source code is provided, you will have to compile it in order to get a working filter. Once you have compiled the project you will need to take the following steps to install:
- Run REGEDT32.EXE and modify the server’s registry as follows. Select the Filter DLLs key in HKEY_LOCAL_MACHINECurrentControlSetServicesW3SVCParameters. Add a local path to authfilt.dll, usually C:WinNTSystem32InetSrvauthfilt.dll. The filter entries are separated by commas. The order is important, if you have other authentication filter with the same priority, the first one listed will receive the authentication request.
- Copy the authfilt.dll file to the directory you specified in the registry.
- Make sure the System account have execute rights on the filter dll file.
Edit the userdb.txt file so it contains valid users and passwords. The format of the file is:
- Copy the userdb.txt file to the directory you specified in the authfilt.h header file for the user database.
- Make sure the System account have read rights on the userdb.txt file.
- Restart the WWW service.
Last updated: 31 October 1998
